Final Caller Intent Summary

This report visualizes in a histogram the caller intents collected at both the entry and exit points of a given call quantifying each by a raw count. The data in this table can be derived from the Caller Intent Transition report but is presented in this format to give an alternative focus.

Note: This report is applicable only for clients using the IVR channel.

Notes:
Some filters allow you to choose whether the visualization data containing specified filter values or else excludes this subset of data.

Clicking Include values displays only those data possessing the selected values. All other data are hidden from the visualization.

By contrast, clicking Exclude values displays only those data that do not possess the selected values.

Toggle specifying whether to include or exclude values indicated in the filter

Date

The Date Range filter is a slider with two moveable sides. By narrowing the date range, you display only data falling within the range.

Visualization of the Date Range slider

In addition to the slider, the filter allows you to specify start and end points to the range by time of day as well as by date by clicking the Start and End regions, clicking a second time on the time of day, and then manually entering a new time of day.

Visualization of clickable regions in Date Range slider to specify start and end times with date picker

Visualization of time-of-day region in one of Date Range slider's date pickers

To select a date with the date picker, click the Start region to pick a date from the date picker widget. Do the same with the End region.

Visualization of calendar region in one of Date Range slider's date pickers

Call Outcome

By selecting one or more call outcomes, you refine your displayed data-set to include only call data with the selected outcomes.

  • Select all available outcomes by selecting All.
  • Select only one outcome by first clearing the All checkbox, and then selecting the name of the outcome whose data you would like to see visualized.

  • Select several outcomes (but a subset of all outcomes) either by performing one of the following two actions:

    • Clear the All checkbox, and then select the names of the outcomes whose data you would like to see visualized.
    • Select the All checkbox (or ensure it is already selected), and then clear the names of the outcomes whose data you would NOT like to see visualized.

Exit Reason

By selecting one or more exit reasons, you refine your displayed data-set to include only call data with the selected exit reasons.

  • Select all available exit reasons by selecting All.
  • Select only one exit reason by first clearing the All checkbox, and then selecting the name of the exit reason whose data you would like to see visualized.

  • Select several exit reasons (but a subset of all exit reasons ) either by performing one of the following two actions:

    • Clear the All checkbox, and then select the names of the exit reasons whose data you would like to see visualized.
    • Select the All checkbox (or ensure it is already selected), and then clear the names of the exit reasons whose data you would NOT like to see visualized.

Custom filters

This report accommodates customizable filters.

Customizable filters narrow the scope of the reported dataset by including or excluding data with identifiable attributes. These attributes may be about the caller, the call itself, or about an event that may have happened during the call.

For example, one possible customizable filter you can add and customize in this view is Caller Type, in which you can narrow the reported data to include, or exclude, only those data with the selected caller type.

Visualization of an example custom filter

For more information about how to add customized filters to your view, contact your Nuance Professional Services representative.

Note: If you would like to modify this or any report, Nuance Communications, Inc. recommends you contact Nuance Professional Services.
